LEDs and Luminaire Test Solutions

Safety and Performance Standards (IEC 60598-1:2020, IEC 62722-2-1:2023)
IEC 60598-1:2020 specifies general safety requirements for luminaires, covering aspects such as mechanical strength, electrical insulation, protection against electric shock, fire resistance, and environmental adaptability. This ensures the reliability and safety of LED lighting products across various applications. Additionally, IEC 62722-2-1:2023 focuses on the performance of LED luminaires, addressing key parameters such as luminous flux, efficacy, color consistency, lumen maintenance (L70/L80/L90), and thermal management. These criteria help guarantee the long-term efficiency and stability of LED lighting systems.

Photometric and Energy Efficiency Evaluation (CIE 121:1996, IS 16101:2012, IS 16104:2012)
CIE 121:1996 provides guidelines for the photometric measurement of road lighting luminaires, emphasizing luminous intensity distribution, glare control, and visual comfort to optimize illumination quality. Meanwhile, IS 16101:2012 and IS 16104:2012 establish the energy efficiency and safety requirements for LED lighting in the Indian market. These standards define efficiency grades, power factor requirements, harmonic limitations, and electromagnetic compatibility to ensure compliance with energy-saving and environmental protection standards.

Standard:

Part 1	IEC 60598-1:2020	Luminaires – Part 1: General requirements and tests
Part 2	IEC 62722-2-1:2023	Luminaire performance – Part 2-1: Particular requirements-LED luminaires
Part 3	CIE 121:1996	The Photometry And Goniophotometry Of Luminaires
Part 4	IS 16101: 2012	General Lighting-LEDs and LED Modules-Terms and Definitior
Part 5	IS 16104: 2012	d.c.OR a.c. Supplied Electronic Control Gear for LED Modules-Performance Requirements

Part 1 IEC 60598-1 Edition 9 Luminaires – Part 1: General requirements and tests

LISUN supplies the fully test solutions for the following IEC 60598-1:2020, please see the below excel table:

IEC 60598-1:2020 Clause and Subject	LISUN Model
Clause 4.4.4 Lampholders	GNG-G5H/GNG-G13H
Clause 4.12.4 Screwed and other fixed connections	CH338
Clause 4.12.5 Screwed glands shall comply with the following test.	LWMF-1
Clause 4.13.1 Mechanical strength	IK01-06
Clause 4.13.3/4 Test finger	SMT-529T
Clause 4.13.6 (Figure 25)Rotating Barrel Drop Test Machine	LS-DDT1-B
Clause 4.14.2 Mechanical fixings	LS-WJ62
Clause 4.14.3 Adjusting devices testing	DJTJ-1
Clause 4.18 Resistance to corrosion	YWX/Q-010
Clause 4.20 Rough service luminaires – Vibration requirements	LVD-100KG-6D
Clause 4.24 Photobiological hazards	EN62471-C
Clause 4.26.3 Lamp test chain	DJSYL-1
Clause 8.2 Protection against electric shock	SMT-529T
Clause 9.2.1 (Figure 6) Dust proof luminaire tests	SC-015
Clause 9.2.3-9.2.9 Drip-proof luminaires	JL-X
Clause 10.2.1 Test – Insulation resistance	WB2681A
Clause 10.2.2 Test – Electric strength	WB2673C
Clause 10.3 Touch current, protective conductor current and electric burn(Figure G2/G3/G4)	MNTC-G2/G3 & MNTC-G4
Clause 11 Creepage Distances and Clearance	CK-1
Clause 12.3 Endurance test	GDJS-010A
Clause 12.4 Thermal test (normal operation)	TMP-LM
Clause 13.2 Resistance to heat(Figure 10)	ZBP-T & GW-225
Clause 13.3.1 Resistance to flame test	ZY-3
Clause 13.3.2 Resistance to ignition testing	ZRS-3H
Clause 13.4 Resistance to tracking(Figure 11)	TTC-1

Part 2 IEC 62722-2-1:2023 Luminaire performance – Part 2-1: Particular requirements-LED luminaires

LISUN supplies the fully test solutions for the following IEC 62722-2-1:2023, please see the below excel table：

IEC 62722-2-1:2023 Clause and Subject	LISUN MODEL
Clause 8.1 Luminous flux	LPCE-2(LMS-9000)
Clause 8.3 Luminaire luminous efficacy
Clause 8.2 Luminous intensity distribution, peak intensity and beam angle	LSG-6000
Clause 9 Chromaticity coordinates, correlated colour temperature (CCT) and colour rendering	LMS-6000
Clause 10 LED luminaire life	LEDLM-84PL

Part 3 CIE 121:1996 The Photometry And Goniophotometry Of Luminaires

LISUN supplies the fully test solutions for the following CIE 121:1996, please see the below excel table:

CIE 121:1996 Clause and Subject	LISUN MODEL
Clause 2.2.1 Luminaire data per 1 000 lm (of lamp flux)	LPCE-2(LMS-9000)
Clause 2.2.4-2.2.7 Light output ratio (of a luminaire)
Clause 6.3 Luminous flux measurements on luminaires
Clause 2.2.2 Luminous intensity distribution (of a luminaire)	LSG-6000
Clause 2.4.1-2.4.3 Photometer
Clause 3 CO-ORDINATE SYSTEMS FOR THE PHOTOMETRY OF LUMINAIRES
Clause 6.1.3 Photometric measurements on luminaires
Clause 6.2 Luminous intensity distribution measurements
Clause 2.2.3 Ballast lumen factor	HCS-109A
Clause 2.3.6 Reference ballast
Clasue 7.4 Ballast lumen factor
Clause 2.4.4 Illuminance meter	LMS-6000 And PHOTO-200
Clause 6.6 Illuminance measurements
Clause 6.3 Luminous flux measurements on luminaires	LMS-6000L And PHOTO-200L

Part 4 IS 16101: 2012 General Lighting-LEDs and LED Modules-Terms and Definitior

LISUN supplies the fully test solutions for the following IS 16101: 2012 , please see the below excel table:

IS 16101: 2012 Clause and Subject	LISUN Model
Clause 3.2 Optical Radiation Safety	EN62471-C
Clause 3.3 Retinal Hazard	EN62471-P
Clause 3.8-3.10 Chromaticity Coordinates and Colour Rendering Index	LPCE-2(LMS-9000)
Clause 3.19/3.45 Junction Temperature and Thermal Resistance	T5
Clause 3.23-3.26 Luminous Flux and Luminous Intensity	LSG-1890B

Part 5 IS 16104: 2012 d.c.OR a.c. Supplied Electronic Control Gear for LED Modules-Performance Requirements

LISUN supplies the fully test solutions for the following IS 16104: 2012, please see the below excel table：

BS IS 16104 Clause and Subject	LISUN Model
3.1 Total Circuit Power	DC3005
3.2 Circuit Power Factor	LS2050B
5.1 Classification according to the load	M9822B
7.3 Capacitive Load Requirement
12. Test for Reduced LED Modules  Resistance	WB2681A
13.1 The control gear shall be subjected to a temperature cycling shock test	GDJS-015B
Annex A.3 Firgure 2 Measurement of impedance at audio-Frequencies	FD2810B
Annex B a guide to quoting product life and failure rate	LEDLM-80PL
