Exploring the Different Types of Probes Used with Digital Oscilloscopes

Introduction
Digital oscilloscopes are essential pieces of equipment for every situation in which it is necessary to analyze and measure electrical signals. If you choose the right probe for your purposes, you can be confident that the results of your measurements will be accurate and reliable. Without probes, capturing signals from the device under test (DUT) and transferring them to the oscilloscope is not feasible.

In this section, we are going to have a look at the various probes that are compatible with digital oscilloscopes. It is essential to have a solid understanding of the attributes, advantages, and drawbacks of each form of probe that is available before selecting a probe to meet your measurement needs. This is because there are many kinds of probes.

Passive Probes
Because passive probes are very affordable and simple to use, they are the form of probe that is used the most often. Coaxial cable and a resistive voltage divider are the two components that make up each probe.

Because passive probes are not dependent on the kind of signal being sent, they may be used to take any kind of measurement with ease. The bandwidth of these types of devices typically ranges from several hundred to several gigahertz.

Passive probes provide a number of advantages, the most notable of which are their cheap cost and simplicity. They have a straightforward operation and do not call for any extra power sources. Nevertheless, passive probes are not without their drawbacks and restrictions.

By loading the circuit that is being tested, their increased input capacitance has the potential to induce distortion in the measured value, which is more likely to occur at higher frequencies. In addition, since their ground leads are longer, there is a possibility that they may contribute additional noise to the measurement.

Active Probes
Enhanced performance and reduced input impedance are two benefits that active probes provide to high-frequency applications that are quite helpful. Because the probe head has active electronics, the capacitive loading effect may be reduced, and there is much less noise as a result.

Active probes often have a bandwidth that is larger than that of passive probes. The active probe’s bandwidth may range anywhere from several hundred megahertz to several gigahertz.

One of the key advantages of active probes is their high input impedance, which decreases the loading influence on the circuit that is being monitored.

This advantage may be found in active probes. In addition to this, they have a lower level of background noise and a better quality signal. Active probes, on the other hand, often need an extra power source and are sold at a greater price than passive probes.

Current Probes
Current probes are designed specifically for measuring alternating current, as the name of the tool suggests. They are used in situations in which it is not feasible to establish a direct connection to the circuit, or when it is necessary to measure current without causing the circuit to be disrupted in any way. The configuration of a current probe is what defines whether it is active or passive in operation.

The generation of a magnetic field allows for the measurement of current using passive probes. They won’t damage anything, and they won’t get their hands on the circuit itself. As a result of their limited frequency response, passive current probes often only provide accurate results for tests at low frequencies.

A current sensor and electrical amplification components are both included inside the heads of active current probes.

Because of their wider bandwidth and higher sensitivity, active probes are more suited for monitoring high-frequency currents than passive probes. This is because active probes are more accurate. Active current probes often include features such as variable gain and filtering as standard fare.

Differential Probes
A differential probe may be used to measure the voltage at any two points in a circuit, regardless of their location. With their assistance, topics like noise, common-mode rejection, and differential signaling in balanced systems may all be investigated.

Differential probes are outfitted with two inputs that may be utilized to link to the locations of the target points of interest.

Due to the strong common-mode rejection ratio (CMRR) of the differential probes, it is feasible to conduct measurements with a low level of noise and interference. LISUN provides the best oscilloscopes in the market.

A few examples of popular applications include motor drive analysis, testing automobiles, and testing power electronics. There are two types of differential probes: passive and active, and each has its unique bandwidth and voltage sensitivity characteristics.

High-Voltage Probes
In order to measure high-voltage signals in a secure manner, specialized apparatus, such as a high-voltage probe, is required. These probes are an absolute need for any application that involves voltages that are outside of the input range of standard oscilloscope probes.

Some examples of such applications are high-voltage power electronics and electrical distribution systems. High-voltage probes may either be passive or active, depending on the user’s preference.

Resistive voltage dividers are used by passive high-voltage probes in order to bring the very high voltage down to a level that is compatible with an oscilloscope. In most cases, they are able to function properly at voltages ranging from a few hundred to several thousand volts. Measurements of high voltage that are taken using a passive probe are simple to do and may be used in any context.

A probe head of an active high-voltage tester will typically have an active voltage divider built into it. As a direct consequence of this, the frequency responsiveness and accuracy could be enhanced in comparison to passive probes. Active high-voltage probes often come equipped with a variety of features, such as configurable attenuation ratios and customizable bandwidth settings.

Specialized Probes
The above-mentioned general-purpose probes are only the tip of the iceberg when it comes to the variety of probes available for usage in various measuring contexts. A few illustrations are:

Differential Active Probes: These sensors are optimized for differential signal measurements at high frequencies. Applications such as high-speed data transfers and differential signal processing may take advantage of their low noise and excellent common-mode rejection.

Logic Analyzer Probes: To examine digital signals, oscilloscopes pair with logic analyzer probes. Digital waveforms may be captured and analyzed with their help, and they also provide sophisticated triggering and decoding options. If you need to troubleshoot digital circuits, protocols, or embedded systems, you need a logic analyzer probe.

Fiber Optic Probes: In order to measure optical signals, fiber optic probes are used. To analyze lightwave signals precisely in fields as diverse as telecommunications, fiber optic communications, and optical networking, they have a fiber optic connection that plugs into the oscilloscope.

Temperature Probes: The temperature probe is a specialized probe for taking temperature readings. Thermocouples or resistance temperature detectors (RTDs) are common temperature sensors found on these probes. They allow for the monitoring and measuring of temperatures in electrical and electronic circuits and power distribution systems and thermal management software.

Conclusion
The accuracy and reliability of your measurements will depend on the probe you choose for digital oscilloscopes. While passive probes are less expensive and may be used for a variety of purposes, active probes provide superior performance, especially when measuring at high frequencies.

Specific measurement requirements may be met by using a current probe, differential probe, or high-voltage probe. In addition, specialist probes, such as those designed for use with a logic analyzer, a fiber optic cable, or a temperature gauge, provide even more sophisticated functionality. You may choose the probe that is ideal for your measuring needs by learning about its features and how it can be put to use.
