LISUN RB-3 Adjustable Resistance Ballast – After Sales Questions and Answers

RB-3 is designed according to the following standard requirements: IEC 60929 (GB/T15144), ANSI-ANSLG-C78.81, ANSI-ANSLG-C82.11, IEC62776, GB/T-15144 double-ended fluorescent lamp adoptting the IEC 60081 (GB/T10682) and the single-ended fluorescent lamp adoptting the IEC 60901 (GB/T17262)

The RB-3 works with HFP-800 (High Frequency Power Supply ) and LPS-3 (Auxiliary Power Supply) to be an IEC Standard Test System which used to test the Frequency Fluorescent Lamp such as T5 Tube. Please visit this page to view How to Measure the High Frequency Fluorescent Lamp.

RB-3_Adjustable Resistance Ballast

Specifications:
• Available current range: 0~0.700A
• Impedance range: 100~2047Ω
• Impedance tolerance range: ±0.5% (Under calibration current). ±1% (Any current between 50% calibration current)
• Within the range of impedance: series inductance of impedance is less than 0.1mH, parallel connection capacitance is less than 1nF

Q1: RB-3 has output terminals in front, how to connect
A1: The functions of the front and rear panel output terminals are the same, just use one of them. Note: When using one group of terminals, the other group of terminals must not be connected with any wire, otherwise there may be unpredictable danger.
