LED coated with phosphor powder on the LED chip to achieve white light emission. There are three main methods to realize white light with phosphor powder, but they are not completely matured. So the application of LED in the field of illumination is seriously affected by LED. Specifically, the first method is applied to the blue LED chip which can be excited by the yellow phosphor blue light, the ...
As well as we know that for the LED luminaires lumen test, the CIE121: 1996 Clause 6.1, CIE127-2007 Clause 6.2 and IES-LM-79-08 Clause 9.0 are mentioned two luminous flux test method: the first is adoption integrating sphere+photometer or spectrometer(recommend by CIE121: 1966 Clause 6.1.1, CIE127-2007 Clause 6.2.and IES-LM-79-08 Clause 9.0), this kind of test method is relative measurement method...
HCS-109A has two functions: one is high frequency ballast; second is high frequency digital power meter. As above picture show, after we connected instrument with test samples, high frequency constant power source will output high voltage to start test lamp (tube), high frequency constant power source output frequency range is 20KHz-26KHz, it can provide continuously adjustable current 100mA-500m...
During the measurement of luminous flux with integrating sphere, comparing with common lighting source, the luminous flux test accuracy of LED lighting source have given huge challenge to the testing equipments. On the one hand, LED light source have outstanding directively characterizes than other ordinary light sources. Normally it wouldn’t uniformly emit lighting at all the direction on the w...
The ideal integrating sphere paint should have below performances: 1. High-Lambert characteristics (good diffuse reflection characteristics) 2. High reflectance in a wide wavelength range 3. High stability 4. Easy construction 5. Easy to remove The history of integrating sphere coating: In 1934, Principle of Optics mentioned the description of principle of integrating sphere and the formulations o...
According to IESNA-LM-79-80, when spectroradiometer integrating sphere system tests LED flux, light source’s self-absorption can influence test result, therefore, it usually introduces Auxiliary Lamp. The induction of absorption Auxiliary Lamp can solve the absorption problem of the tested lamp itself. How to use Auxiliary Lamp correctly? Lisun LPCE-2(LMS-9000A) High precision Spectroradiomet...
Goniophotometer measures light intensity performance measurement of luminaries and light source, which is the photometry value in different directions in space and color distribution. Goniophotometer should run in dark room, and what are the requirements for the test environment? The size requirements for dark room: for example, such as LISUN LSG-6000 LM-79 Type C Mirror Goniophotometer System. Ac...
As far as we known that there have several type spectroradiometer, such as CCD spectroradiometer, mechanical scanning spectrophotometer etc. Generally, the type of spectrometer depend on what’s kind of lamp will be test, because the spectrometer is designed according to light-emitting characteristics. There have two kind of spectrometer in the market: one is Fast CCD Spectroradiometer; another i...
As we known that the quality of LED products depend on lumen, lumen efficiency temperature and CRI etc parameters, the general test device is application with spectroradiometer & integrating sphere system to measuring electrical, photometric and colorimetric parameters. This system mainly testing lumen, CCT, CRI, spectrum, SDCM, voltage, current, power and power factor etc. As general test dev...
