Product No: LS-B21
The Electrical Casing Compression Test Device complies with the requirements of IEC 60670-1:2021 Clause 15.2 and 15.5.
Standard:
IEC 60670-1 “Boxes and enclosures for electrical accessories for household and similar fixed electrical installations – Part 1: General requirements”
Specification:
• Control method: touch screen + PLC control;
• Compression method: electric;
• Compression force value: 50-1000N (can be set), sensor accuracy: 1%FS;
• Compression time: 1-99min(s) can be set arbitrarily. After the compression time is up, the pressure will be automatically relieved and withdrawn. The deformation was measured 1 hour after the load was removed.
• Displacement resolution: 1mm
