DC Voltage Dips and Interruptions Generator

Product No: CSS61000-29

Leave a Message

Description

CSS61000-29 DC voltage dips and interruptions generator is specially designed according to the characteristics and requirements of EMS measurement under a sudden reduction or interruption of the voltage at the DC power input port.

Standard:
IEC61000-4-29/EN61000-4-29/GB/T17626.29 “Electromagnetic compatibility Testing and measurement techniques Voltage dips, short interruptions and voltage variations on d.c.input power port immunity tests”

LISUN Model	CSS61000-29A	CSS61000-29B	CSS61000-29C	CSS61000-29D
The capacity of the EUT (DC)	Max. 120V/5A	Max. 120V/10A	Max. 240V/5A	Max. 240V/10A
Dip (interruption) time	1～60,000mS
Dip (interruption) interval time	1～9,999mS
The number of dip (interruption)	1～9,999 times

Large LCD touch screen is with built-in Windows CE. If required to comply with IEC61000-4-11 or GB/T17626.11 Pls. click here for AC Voltage Dips and Interruptions Generator.
