Product No: GNGPL-6243BILD
Die beiden seitlichen Schutzkontakte werden nacheinander mit der Vomichtung nach Bild 43a und Bild 43b mit einem Drehmoment von 100 ±5 Ncm fur 1 min ±5s belastet. Dabei werden zwei Pruflinge im Uhrzeigersinn und der dritte Prufling gegen den Uhrzeigersinn gepruft.
Nach dieser Prüfung muss die Lehre 4 eingeführt werden können.
Diese PrÃfungen werden an neuen Pruflingen durchgeführt.
Bild 43a- Vorrichtung zur Prüfung der seitlichen Schutzkontakte
Bild 43b – Hilfslehre für die Vorrichtung nach Bild 43a
