Masks Flame Retardant Performance Tester
Masks Flame Retardant Performance Tester

Masks Flame Retardant Performance Tester

Product No: WKS-1208

Leave a Message

=
  • Description

  • WKS-1208 Masks Flame Retardant Performance Tester is used to test the burning performance of the mask after contacting the flame at a certain linear velocity. It is special test instrument for the flame retardant performance of masks.

    Standard:
    GB 19083-2010、YY 0469-2011、GB 2626-2006、GB 19083-2003

    Specifications:

    Projects

    Spec.

    Line speed of head mould automatic movement

    (60±5)mm/s

    Flame height

    40±4mm ajustable

    Height between flame and burner tip

    (20±2)mm

    Temperature between flame and burner tip

    (800±50)℃

    The distance between the top of the burner and the lowest point of the mask

    (20±2)mm

    Height of burner

    Adjustment range: 30mm

    Wall thickness of the metal head mold

    2～3mm，flame and burning resistance

    Dimension

    980*550*350mm

    Continuous ignition time and ignition time timer

    0～9999.9s, accuracy±0.1s

    Power supply

    AC220V，50Hz，50W



    Features

    • PLC touch screen control system; make the test more convenient, easy to operate and visualize.
    • The mask fixture is a metal human head mold which can fully simulate the actual use of the mask.
    • The height of the burner is adjustable.
    • The burner is automatic timing positioning.
    • The burning time and flame retardant time are automatically recorded and displayed digitally.
    • Equipped with flame temperature measurement probe and flame temperature indicator.
    • Automatic control system, automatic ignition.
    • The burner is equipped with combustible gas interfaces such as propane (liquefied petroleum gas).
    • Automatic timing, automatic storage of test data, easy to retrieve experiment report.
    • Equipped with flame temperature measurement and detection thermocouple.
