IEC 60669-1:2017 Switches for household and similar fixed electrical installations – Part 1: General requirements

Scope

IEC 60669-1:2017 applies to manually operated general purpose functional switches, for alternating current (AC) only with a rated voltage not exceeding 440 V with a rated current not exceeding 63 A, intended for household and similar fixed electrical installations, either indoors or outdoors. For switches provided with screwless terminals, the rated current is limited to 16 A. This fourth edition cancels and replaces the third edition published in 1998, Amendment 1:1999 and Amendment 2:2006.

IEC 60669-1:2017 Switches for household and similar fixed electrical installations – Part 1 General requirements

LISUN supplies the fully test solutions for the following IEC 60669-1:2017, please see the below excel table:

IEC 60669-1:2017 Switches for household and similar fixed electrical installations -Part 1: General requirements	LISUN MODEL
Clause 10 Protection against electric shock	SMT-1175
Clause 11 Provision for earthing	WB2678A
Clause 12.2.5 deflection test (Figure 10 )	WDT-1
Clause 12.3.12 Deflecting device	JCY-2
Clause 13.15.1-13.15.2 Heating Cabniet and Refrigerator	GDJS-015B
Clause 15.3 Resistance to humidity
Clause 21 Resistance to heat
Clause 15.1 Resistance to ageing
Clause 15.1 Resistance to ageing	ZBP-T
Clause 15.2.3 Protection against harmful effects due to ingress of water	JL-X
Clause 16 Insulation resistance and electric strength	WB2681A
Clause 17 Temperature rise	WS-1
Clause 18 Making and breaking capacity	CZKS-6 & DFX-20
Clause 19.1 Test for switches intended for inductive loads	DFX-WD20A
Clause 19.2 Test for switches intended for externally ballasted lamp loads	DFX-60
Clause 19.3 Test for switches intended for self ballasted lamp loads	SBLL-3P20A
Clause 20.2 Pendulum hammer test	IK07-10
Clause 23 Creepage distances, clearances and distances through sealing compound	CK-1
Clause 24.1 Glow Wire test	ZRS-3H
Clause 24.2 Resistance to tracking	TTC-1
Clause 25 Resistance to rusting	YWX/Q-010
