IEC 62560: 2011 Self-ballasted LED-lamps for general lighting services by voltage > 50 V – Safety specifications

The IEC 62560:2011 standard specifies safety requirements for self-ballasted LED lamps intended for general lighting purposes, with voltages greater than 50 V and up to 250 V. It focuses on lamps that incorporate control gear and can be directly connected to the mains supply. The standard addresses critical safety aspects, including electrical, thermal, mechanical, and fire hazards, ensuring the lamps’ safe operation under normal and abnormal conditions. These safety measures apply to LED lamps with Edison screw or bayonet cap bases and are essential for protecting users from potential risks.

Additionally, IEC 62560:2011 outlines specific tests and criteria to verify compliance with safety requirements. These tests include dielectric strength, insulation resistance, temperature rise, and endurance under specific environmental and operational conditions. The standard aims to harmonize safety practices across manufacturers, ensuring consistent quality and safety for end-users worldwide. The document also covers markings and instructions that manufacturers must provide for proper usage and maintenance.

LISUN supplies the fully test solutions for the following IEC 62560:2011, please see the below excel table:

IEC 62560:2011 Clause and Subject	LISUN Model
3.1 Self-ballasted LED-lamp	WT5000
3.5 (charpter 10) cap temperature rise	TMP-L
3.10 ultraviolet hazard efficacy of luminours radiation	EN62471-C
6.1 Cap Interchange ability(Table 1)	GNG-E27
6.2 Bending moment and mass imparted by the lamp at the lamp holder (table 2)	LS-WJ62
7. Protection against accidental contact with live part (figure 2)	SMT-IP20T
8.2 Insulation resistance	WB2681A
8.3 Electric strength	WB2671B
9.2.1 Torsion resistance of unused lamps(figure 3)	CH338
11. Resistance to heat (figure 5)	GW-225 and ZBP-T
12. Resistance to flame and ignition	ZRS-3H
14. Creepage distance and clearances	CK-1
17. Photobiological safety	EN62471-C
18.2 Ingree protection for IPX4 test	JL-34
