IEC 62613-1:2019 Plugs, socket-outlets and ship couplers for high-voltage shore connection(HVSC)systems – Part 1: General requirements

This part of IEC 62613-1:2019 applies to accessories with
• three phases and earth with pilot contacts,
• one pole for neutral.

These accessories have rated currents not exceeding 500 A and rated operating voltages not exceeding 12kV 50/60 Hz.
NOTE 1 In some countries, the term *ground” is used instead of “earth”.

These accessories are primarily intended for use outdoors, in a seawater environment, for the shore supply of ships (ship-to-shore connection), in an ambient temperature within the range of -25 ‘C to +45C.
NOTE 2 In some countries, other ambient temperatures prevail and are considered.

LISUN supplies the fully test solutions for the following IEC 62613-1:2019, please see the below excel table:

IEC 62613-1:2019 Plugs, socket-outlets and ship couplers for high-voltage shore connection(HVSC)systems – Part 1: General requirements	LISUN MODEL
Clause 9 Protection against electric shock	SMT-02T50
Clause 10 Provisionsfor protective earthing	WB2678A
Clause 11.3.1 flexing tests for copper conductors	JCY-2
Clause 11.3.2 pull-out tests for copper conductors	PULL-2000KG
Clause 13 Resistance to ageing of rubber and thermoplastic material	GW-500
Clause 18.2 torque Test	LS-B47
Clause 22.2 torque test
Clause 18.4 proofed against humid conditions	GDJS-015B
Clause Insulation resistance measurement	WB2681A
Clause 21 Temperature rise	WS-1
Clause 23 Impact resistance/Drop test	LS-B33
Clause 25.1-25.3 Resistance to heat	ZBP-T
	GW-500
Clause 25.4 Glow wire test	ZRS-3H
Clause 26 Corrosion and resistance to rusting	YWX/Q-010
