IEC 62640:2011 Residual current devices with or without overcurrent protection for socket-outlets for household and similar uses

IEC 62640:2011 specifies requirements for residual current devices (RCDs) with or without overcurrent protection intended for household and similar applications. These devices are designed to provide protection against electric shock, fire hazards, and excessive residual currents by disconnecting the circuit when leakage currents exceed specified thresholds. The standard covers performance characteristics, testing procedures, and installation guidelines to ensure safety and reliability in various operating conditions.

Additionally, IEC 62640:2011 outlines the classification, marking, and functional aspects of these devices, including parameters such as rated voltage, current, and tripping characteristics. It also defines mechanical and electrical endurance requirements, ensuring that RCDs maintain effectiveness over time. The standard applies to socket-outlet-type devices used in residential, commercial, and similar environments, providing guidance for manufacturers, testing laboratories, and regulatory authorities.

LISUN supplies the fully test solutions for the following IEC 62640:2011, please see the below excel table：

IEC 62640:2011 Clause and Subject	LISUN Model
4.7.1 Protection against of solid foreign objects	SMT-02T50 And SMT-DT1 And SC-015
4.7.2 degree of protection against harmful ingress of water	JL-34 And JL-56
8.3.2 Clearance and creepage distances	CK-1
8.7 Temperature rise	WS-1
8.12 Resistance of the insulation against impluse voltages	WB2681A
8.13 Mechanical and electrical endurance	WB2671B
8.16.4 Degree of production IP20	SMT-IP20T
9.7.1.5 Power Cord Flexibility Bending Tester	SW-6
9.7.2.12 Screwless Terminal Deflection/Bending Test Device	JCY-2
9.12 Resistance to humidity	GDJS-015B
9.14.2 surge generator test & Ring wave generator	SG61000-5 And RWG61000-12
9.17.2.1 Test procedure for on-load test	DFX-20
9.18.1 Resistance to mechanical shock	LVD-100KG
9.18.2 Impact test apparatus	IK07-10
9.21 Resistance to heat	GDJS-015B
9.21.3 Ball pressure test (figure 26)	ZBP-T And GW-225
9.22 Resistance to abnormal heat and to fire	ZRS-3H
