IEC TS 62735-1:2015 Direct current (DC) plugs and socket-outlets for information and communication technology (ICT) equipment installed in data centres and telecom central offices – Part 1: Plug and socket-outlet system for 2.6 kW

The IEC TS 62735-1:2015 standard specifies the technical requirements for direct current (DC) plug and socket-outlet systems designed for use with information and communication technology (ICT) equipment installed in data centres and telecom central offices. It focuses on a DC power system with a maximum capacity of 2.6 kW, providing guidance on design, safety, and performance criteria to ensure reliable and efficient power delivery in critical ICT environments.

LISUN supplies the fully test solutions for the following IEC TS 62735-1:2015, please see the below excel table:

IEC TS 62735-1:2015 Direct current (DC) plugs and socket-outlets for information and communication technology (ICT) equipment installed in data centres and telecom central offices – Part 1: Plug and socket-outlet system for 2.6 kW LISUN MODEL
Clause 10.2 Protection against electric shock SMT-PB
SMT-1150
GW-500
LS-B08
Clause 10.3 Creepage Distance CK-1
Clause 27 Creepage distances, clearances and distances through sealing compound
Clause 10.5-10.7 Gauge for checking non-accessibility of live parts, SMT-20N
SMT-1N
Clause 11.2 Resistant to corrosion YWX/Q-010
Clause 12.2.10 corrosion
Clause 29 Resistance to rusting
Clause 11.4 Earthing Resistance WB2678A
Clause 12.2.5 torque test LS-B47
Table 4 and Table 18
Clause 12.2.5 damage to the conductor WDT-1
Clause 12.2.6 Table 2 Pull test LNSYJ-1
Clause 12.2.5 Insulation resistance measurement JCY-2
Clause 12.3.12 deflecting stress
Clause 13.19 Heating Cabniet GW-500
Clause 25 Resistance to heat
Clause 16.1 Resistance to ageing GDJS-015B
Clause 16.3 Resistance to humidity
Clause 17 Insulation resistance and electric strength WB2681A
Clause 19 Temperature rise WS-1
Clause 22 Force necessary to withdraw the plug BCL-1
Clause 23.2 The effectiveness of the retention of the cable(Figure 17) LS-B07
Clause 23.4 Felxing test(Figure 18) SW-6
Clause impact-test apparatus(Figure 19) IK07-10VT
Clause 24.5 Impact test in a freezer(Figure 20) DWC-1
